NEW! 2023 YORK 150 ton Air Cooled Chiller YVAA-0153XX46 Available 10-17-23

NEW! 2023 YORK 150 ton Air Cooled Chiller YVAA-0153XX46 Available 10-17-23
$143,500 (USD)
orCall 978-514-3800
Description
Stock can change daily please check with us on availability!
KIG
(Keith Industrial Group Inc.) specializes in NEW Air Cooled Chillers for
industries such as breweries, wineries, manufacturing, plating, plastics, and comfort
cooling. We provide hundreds of units per year from 20 ton up to 323 ton.
This YORK YVAA0153 (150 "ton") dual semi hermetic variable speed screw chiller is currently being made for stock and due:
10-17-2023
Please
check with us to confirm availability dates as they can change daily based on
incoming sales orders. Availability dates are when units are due into our San
Antonio, TX, stock yard location.
This is a North American Made York/Johnson Controls Chiller backed by the DIRECT USA service and support network throughout the country.
This special price INCLUDES FREIGHT by flatbed to your location (lower 48 states).
A start up visit charge
must be added to the total and is required to honor 1 year parts and labor
warranty. The start up charge can range from $ 3,700 up to $5,900 depending on
the address and zip code of the site location. PLEASE CHECK WITH
US. Please understand that it is the customers obligation to get the
chiller installed and under power with appropriate piping and flow prior to the
technicians arrival. The York start up is a check and confirmation that
is installed and set correctly to initiate the warranty. KIG guides you
through this process and assists in scheduling.
This special price is for
payment by wire or cleared business check prior to shipment. For payment
"terms" we will direct you to one of our leasing companies.
Sales tax must be added for your particular state unless you provide a
local state tax exemption certificate, if applicable to your state (example:
partial or full tax exemption for manufacturing).
Voltage code- (460/3/60) ampacity 274, max fuse 350
R-134a Refrigerant (Fully Charged)
2 VSD Hermetic Screw Compressors
SP NF Disconnect Switch w/ lockable Handle
BACnet/modbus/N2 (Native) English
Actuated Suction Service Valves
Standard Part Load (IPLV) Efficiency
Water Box Heaters (requires separate 120v power supply)
150psig DWP Waterside
ASME Pressure Vessel & Associated Codes
2-Pass Evaporator
Back Fluid INlet (opposite control panel end)
Thermal dispersion flow switch
6" connections
All Aluminum Microchannel Coils
Low Sound Fans with Variable Speed Control
Wire/ Louvered Enclosure Panels
Low Sound Kit (Level 0 Reduction)
Vibration Isolators- Elastomeric Pads
89" wide x 247" tall
Specifications
Manufacturer | York |
Model | YVAA |
Condition | New |
Mpn | YVAA0153 ABV |
Country/region of manufacture | United States |
Services available | Freight - Check the item description or Contact the seller for details |
Shipping weights | 12,600 Lbs |
Design flow rate | 368 GPM |
