New 2025 YORK 230 ton Air Cooled Chiller YLAA-0230HJ46VSD R454b 460V Next Avail.11/18/25

Stock can change daily please check with us on availability!

KIG, (Keith Industrial Group Inc.) specializes in quality NEW Air-Cooled Chillers for industries such as breweries, wineries, manufacturing, plating, plastics, comfort cooling. We provide hundreds of units per year from 5 tons up to 350 tons.

This YORK YLAA-0230HJ46 VSD "216 ton" scroll chiller is currently being made for stock and:

Next Avail.11/18/25

Note: this is the newest R454b refrigerant accepted in ALL states

A start-up visit charge must be added to the total and is required to honor 1 year parts and labor warranty. Cost ranges from $ 2,300 up to $ 4,500 depending on the address and zip code of the site location. PLEASE CHECK WITH US

·        York / Johnson Controls, YLAA-0230HJ46VSD series air cooled chiller

·        ~ 216 tons of cooling at 44F water / 95F ambient conditions

·        Variable Speed Drive on ALL fans

·        Plate evaporator. Microchannel Coils.

·        R-4545b Refrigerant (Fully Charged) (160 Lbs)

·        2 refrigerant circuits

·        VoltageCode - (460/3/60)

·        MCA: 477 amps / Max fuse: 500

·        6 Scroll Compressors (3 for each circuit)

·        Water through evap: Min. 230 gpm, max 625 gpm. Design flow rate 460 gpm

·        5" inlet and outlet connections (grooved victaulic)

·        SP NF Disconnect Switch w/Lockable Handle

·        Control Transformer

·        Both Low/High Ambient Kit (for outdoor winter use / or high temp summer use) - both ok

·        Hot Gas Bypass on circuit #1

·        Integrated flow switch and Y strainer

·        No water pump or reservoir tank internal

·        89" wide x 276" long x 95" tall

·        Shipping Weight: 9991 /  Operating Weight 10476  lbs

·        Keith Industrial Group, Inc. (KIG) Clinton MA / San Antonio TX
