New 2026 YORK 230 ton Air Cooled Chiller YLAA-0230HJ46VSD R454b 460V Next Avail.12-22-26

Stock can change daily please check with us on availability! KIG, (Keith Industrial Group Inc.) specializes in quality NEW Air-Cooled Chillers for industries such as breweries, wineries, manufacturing, plating, plastics, comfort cooling. We provide hundreds of units per year from 5 tons up to 350 tons.

Availability Status of this YORK YLAA-0230HJ46 VSD "216 ton" chiller:

• Next Avail. 12-22-26

A start-up visit charge must be added to the total and is required to honor 1 year parts and labor warranty. Cost ranges from $ 2,300 up to $ 4,500 depending on the address and zip code of the site location. PLEASE CHECK WITH US

• York / Johnson Controls, YLAA-0230HJ46VSD series air cooled chiller
• ~ 216 tons of cooling at 44F water / 95F ambient conditions
• Variable Speed Drive on ALL fans
• Plate evaporator. Microchannel Coils.
• R-4545b Refrigerant (Fully Charged) (160 Lbs)
• EER [Btu/W.h] 10.73
• IPLV.IP [Btu/W.h] 18.53
• 2 refrigerant circuits
• 6 Scroll Compressors (3 for each circuit)
• Voltage Code - (460/3/60)
• MCA: 477 amps / Max fuse: 500
• Water through evap: Min. 230 gpm, max 625 gpm. Design flow rate 460 gpm
• 5" inlet and outlet connections (grooved victaulic)
• SP NF Disconnect Switch w/Lockable Handle
• Control Transformer
• Both Low/High Ambient Kit (for outdoor winter use / or high temp summer use) - both ok
• Hot Gas Bypass on circuit #1
• Integrated flow switch and Y strainer
• No water pump or reservoir tank internal
• 89" wide x 276" long x 95" tall
• Shipping Weight: 9991 /  Operating Weight 10476  lbs
